Split large type water electrolysis hydrogen production equipment
Product Features
1.The hydrogen production capacity of a single equipment is20Nm³/h-2000Nm³/h, which can be in the form of hydrogen production stations or containerized layouts
2.Fully automatic microcomputer control with high degree of automation, capable of remote centralized management, human-machine intelligent interface, easy to operate, safe and reliable.
3.The purity of hydrogen gas before purification treatment is 98.5%, the purity of oxygen is 99.7%, and the purity of hydrogen gas after purification treatment is 99.999%.
Technical parameter:
| Type | Hydrogen production | Operating pressure | Hydrogen purity | Oxygen purity | Purity after purification | Dew point after purification | DC power consumption |
| （m³/h） | Mpa/bar | V/V | V/V | （Oxygen content,ppm) | (℃） | （KW.h/m³） | |
| EH-1 | 1 | 1.0/10 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-2 | 2 | 1.0/10 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-5 | 5 | 3.2/32 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-10 | 10 | 3.2/32 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-20 | 20 | 3.2/32 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-30 | 30 | 3.2/32 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-40 | 40 | 3.2/32 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-50 | 50 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-60 | 60 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-80 | 80 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-100 | 100 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-150 | 150 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-200 | 200 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-500 | 500 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-1000 | 1000 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
| EH-2000 | 2000 | 1.6/16 | 99.7% | 98.5% | ≤1 | ≤-70 | ≤4.5 |
